ZOOMLION RT100 100ton Rough Terrain Crane
Model:
RT100
View All >
Category:
Lifting Machinery
Product:
Truck Crane
Brand Name:
ZOOMLION
Dimension (mm):
14247×3620×3960mm
Operating weight (kg):
3339kN.M
Origin:
Jiangsu, China (Mainland)
Min Order Quantity:
1 Unit
Delivery Time:
10 days
Summary
Feature:
Rough Terrain Crane
Condition:
New
Application:
Construction
Brand Name:
ZOOMLION
Model Number:
RT100
Certification:
ISO,CE
Rated Loading Capacity:
100t
Rated Lifting Moment:
3339kN.M
Dimension:
14247×3620×3960mm
Max. Lifting Load:
100t
Max. Lifting Height:
45.6m
Place of Origin:
Jiangsu, China (Mainland)
Warranty:
1 year
Span:
8.0/7.9m
After-sales Service Provided:
Engineers available tc
Specifications
Packaging & Shipping
Packaging Details:
Nude package Shipped by Ro-Ro or Bulk shipment
Delivery Detail:
10 days
Details
Category  Item Unit  Parameter
Dimensions  Dimensions (Length×width×height) mm 16225×3000×3995
Wheel base mm 2650+1650+2900+1650
Track (Front/ Rear) mm 2590
Front/ Rear overhang mm 2660/2135
Front/ Rear extension mm 2325/255
Weight Max. permissible weight kg 54990
Axle load 1st axle kg 11490
2nd axle kg 12000
3rd axle  kg 12000
4th axle kg 9900
5th axle kg 9600
Rated power/rpm kW/(r/min) 390/1900
Max. net power/rpm kW/(r/min) 385/1900
Max. torque/rpm N.m/(r/min) 2500/1000-1400
Travel Max. travel speed km/h ≥80
Min. travel speed km/h ≤5
Min. turning diameter m ≤18.5
Min. turning diameter at boom tip m ≤23
Min. ground clearance mm 307
Approach angle ° 19
Departure angle ° 16
Braking distance (at 30 km/h ) m ≤10
Max. grade ability % ≥60
Fuel consumption per 100 km L 70
Noise Exterior noise level dB(A) ≤88
Noise level at seated position dB(A) ≤90
Main

performance

Max. total rated lifting capacity t 160*
Min. rated working radius m 2.5
Turning radius at turntable tail Counterweight  mm 5110
Auxiliary winch mm 4960
Max. load moment Base boom kN.m 5145
Fully-extended boom kN.m 2115
Fully-extended boom + Jib kN.m 1940
Outrigger span  Longitudinal m 8.99
 Lateral m 7.9
Hoist height Base boom m 14.9
Fully-extended boom m 76.9
Fully-extended boom + Jib m 103.1
Boom length Base boom m 14.4
Fully-extended boom m 78
Fully-extended boom + Jib m 107.4
Jib offset angle ° 0、15、30
Working speed Boom raising time s ≤60
Boom fully extended time s ≤760
Max. slewing speed r/min ≥1.5
Outrigger extending and retracting time Outrigger beam Retracting s ≤40
Extending s ≤40
Outrigger jack Retracting s ≤60
 Extending s ≤90
Hoisting speed (single line, 4th layer, no load) Main winch m/min ≥135
Auxiliary winch m/min ≥90
Noise Exterior noise level dB(A) ≤110
Noise level at seated position dB(A) ≤85
